商品の詳細:
|
| ジオテキスタイルタイプ: | Non-Woven Geotextiles | 材料: | PP(ポリプロピレン) PET(ポリエステル) |
|---|---|---|---|
| 重さ: | 100~800g | 応用: | 建築工事、ダム、鉄筋、土木工事、エンジニアリング |
| キーワード: | 不織布ニードルパンチジオテキスタイル、不織布、ポリエステル/PP不織布ジオテキスタイル、ペット不織布、道路用高品質ジオテキスタイル | 使用法: | 生態系法面保護システム、建設プロジェクト、ダム等、都市環境 |
| 破断伸び: | 40%-80%、 | パッケージ: | PP 織バッグ、カスタマイズ |
| ファイバーの種類: | ステープルファイバー、ポリエステル連続フィラメント、長繊維 |
Our Filament Non-woven Geotextile is engineered utilizing a high-precision, direct-spinning thermal process where first-grade polyester chips are converted into unbroken, continuous micro-strands. This infinite fiber network is then densely needle-punched, creating a fabric with an extraordinarily high tensile modulus and exceptional multi-directional puncture resistance. Unlike staple fibers, the unbroken filament matrix ensures the material absorbs tremendous physical impact and lateral movement without stretching or tearing. It serves as an elite-level hydraulic separator and reinforcing base, preventing different soil horizons from intermixing while allowing massive water volumes to pass through smoothly under heavy structural loads.
Specification |
100 |
150 |
200 |
300 |
400 |
500 |
600 |
800 |
Remark |
Quality deviation per unit acreage% |
-6 |
-6 |
-6 |
-5 |
-5 |
-4 |
-4 |
-4 |
|
Thickness,mm≥ |
0.8 |
1.2 |
1.6 |
2.2 |
2.8 |
3.4 |
4.2 |
5.5 |
|
Width deviation for range,%m |
-0.5 |
||||||||
Mightiness at break,KN/m ≥ |
4.5 |
7.5 |
10.0 |
15.0 |
20.5 |
25.0 |
30.0 |
40.0 |
Vertical and horizontal |
Elongation at break,% |
40-80 |
||||||||
CBR bursting strength,KN≥ |
0.8 |
1.4 |
1.8 |
2.6 |
3.5 |
4.7 |
5.5 |
7.0 |
|
Effective aperture O90(O95)mm |
0.07-0.20 |
||||||||
Vertical osmotic coefficient,cm/s |
K x(10-1-10-3) |
K=1.0-9.9 |
|||||||
Tearing strength, KN≥ |
0.14 |
0.21 |
0.28 |
0.42 |
0.56 |
0.70 |
0.82 |
1.10 |
Vertical and horizontal |
Q1: Are you manufacturer or trading company?
A: We are manufacturer.
Q2: Which country did you export?
A: Our products have been exported to more than 20 countries all over the world, including USA, Canada, Poland, Switzerland, Japan, Southeast Asia, The Middle East, Africa, Australia etc.
Q3: What is your MOQ?
A: Normally, our MOQ is 20' container. But we could accept LCL for first trial order.
